Posted on 06/28/201310/01/2016 by admin — Leave a comment

Will Rockford Fosgate T1692 Rockford T165 fit Toyota Tundra

Leonard:

According to the specs below (taken from RF website), those 6x9s are WAY to deep to fit in your Tundra’s front doors. We don’t recommend going over 3.15″ top mount depth. The Rockford T165 will work fine in the read door of your Toyota Tundra.

While it is possible to use more spacers to gain additional top mount depth you will be faced with a second problem. The speakers will get to close or touch the door panel. This will damage the speakers. Per our speaker guidelines for a Tundra you should look for speakers that are below3″ top mount depth. Have you considered our Image Dynamics CTX6x9 bundle? WE have a lot of happy Tundra owners with this setup.

Check us out at:

Friend us on Facebook:http://www.facebook.com/tacotunes

Website: https://tacotunes.com

Add us a friend on Facebook:http://www.facebook.com/tacotunes

YouTube:http://www.youtube.com/tacotunes

Pictures: https://www.tacotunes.com/pictures

Blog: https://www.tacotunes.com/blog

—–Original Message—–
From: [email protected] [mailto:@yahoo.com]
Sent: Friday, June 28, 2013 8:30 AM
To: [email protected]
Subject: Contact Us Requested

You have received a contact request from a visitor to your storefront at http://shop.tacotunes.com:

E-mail Address: xx@yahoo.com

Name: Leonard

Company:

Phone Number:

Request:

I have a 2011 tundra crewmax and I’m putting in Rockford Fosgate T1692, 6×9 in the front and Rockford T165, 6.5 in the rear. What kit would I need for all four speakers?

Thank you,

The Quick Shopping Cart Team

T1692

Get Power series sound quality in a drop-in speaker. These full-range speakers inherent all the coolest features from their big brother component systems. Be prepared, these are more than OEM replacement speakers, their sound quality has been perfected for true Rockford Fosgate fanatics!

CEA-2031 Compliant:

Configuration:

2-Way Full-Range

Midrange Diameter (in):

6″x9″

Midrange Depth (in):

3.43″ (87mm)

Tweeter Diameter (in):

1.0″ (25.4mm)

Tweeter Depth (in):

Frequency Response:

50Hz – 22kHz

Nominal Impedance:

4-Ohm

Power Handling (RMS):

100 Watts RMS 200 Watts MAX

Crossover:

Built-in tweeter crossover High-Pass (HP): 12dB/octave Butterworth

Sensitivity (dB @ 1 watt/1 meter):

90dB

Grilles Included:

Yes

Mounting Hardware:

Shipping Weight:

12.6 Lbs. (5.72 Kg.)

Posted on 05/21/201310/18/2016 by admin — Leave a comment

Focal Integration IS 165 Component Speakers – Toyota Tundra

Focal Integration IS 165 Component Speaker Toyota Tundra

Focal Integration IS 165 Component Speakers in Toyota Tundra

To install Focal Integration IS 165 Component Speakers into your Toyota Tundra, you will want to use tacotunes.com speaker adapters designed to work in your Tundra. The Focal Integration IS 165 Component Speakers require a 5.7” cutout diameter for the mid range speakers. The Focal Integration IS 165 Component Speakers tweeters will require a 1.67″ cutout diameter.

Click HERE to check out our audio products for your Toyota Tundra

Focal Integration IS 165 Component Speakers will fit you your Toyota Tundra without any cutting, drilling or modifying your Tundra.

Summary:

Mid range Driver: 5.7″ cutout diameter

Tweeter: 1.67″ cutout diameter

Top Mount Depth: 2″

Focal Integration IS 165 Component Speaker Manual Toyota Tundra

Max. power	140W
Nom. power	70W rms
Sensitivity (2.83V/1m)	93.2dB
Frequency response (+/-3dB)	60Hz – 20kHz
Magnet	85mm (3.3″)
Voice coil	1” (25mm) x 0-1/4” (7mm)
Tweeter	Processed Aluminum inverted dome tweeter
Cut-out diameter	165mm (6-1/2″)
Type	Coaxial speakers kits
Diameter	6” 1/2

IC 165

Technical characteristics

Diameter:

61/2” (165mm)

Voice-coil diameter:

1” (25mm)

Voice-coil height:

01/4” (7mm)

Magnet:

39/16” (90mm)

Processed Aluminum inverted dome tweeter

Focal® is a trademark of Focal-JMlab®-Tel. (33) 04 77 43 57 00 – www.focal.com – Images may not conform exactly to specific product. Photos L’Atelier Sylvain Madelon – SCL G101216/1

Sensitivity (2.83V/1m):

93.2dB

Frequency response:

60Hz – 20kHz

Accessories:

Supplied grilles

Integrated crossover:

6/6dB/oct

Max. power:

140W

Nom. power:

70W rms

2-way coaxial kit

Adv antages

• High sensitivity

• High soundstage

• Partial horn loading tweeter

• Dynamics and neutrality

• Mounting depth : 2″ (49.9mm)

Woofer crossover

• Processed alumintum inverted dome tweeter

Smoothness an

• Butyl surround d definition without directivity

Excellent reliability

• Partial horn loading

best positioning in the soundstage

• Tilted and rotary mounting

Orientation in the driver axis

• Polyglass cone

Neutral sound without coloration

• Integrated crossover

Easier connection

Integration

Check us out at:

Friend us on Facebook:http://facebook.com/tacotunes

Website: https://tacotunes.com

Add us a friend on Facebook:http://facebook.com/tacotunes

YouTube:http://youtube.com/tacotunes

Posted on 04/29/201310/19/2016 by admin — Leave a comment

JL Audio ZR650 Csi Component Speakers – Toyota Tundra

JL Audio ZR650 Csi Component Speakers in Toyota Tundra

To install JL Audio ZR650 Csi Component Speakers into your Toyota Tundra, you will want to use tacotunes.com speaker adapters designed to work in your Tundra. The JL Audio ZR650 Csi Component Speakers require a 5.5” cutout diameter for the mid range speakers. The JL Audio ZR650 Csi Component Speakers tweeters will require a 1.67″ cutout diameter.

Click HERE to check out our audio products for your Toyota Tundra

JL Audio ZR650 Csi Component Speakers will fit you your Toyota Tundra without any cutting, drilling or modifying your Tundra.

Summary:

Mid range Driver: 5.4″ cutout diameter

Tweeter: 1.67″ cutout diameter

Top Mount Depth: 2 3/4″

JL Audio TR650 CSi Component Speaker Manual Toyota Tundra

ZR650-CSi

2-Way Component System: 6.5-inch (165 mm) Woofer, 1-inch (25 mm) Aluminum Dome Tweeter
Our reference quality ZR component speakers are made for those seeking the highest possible levels of audio performance and are the pinnacle of the JL Audio component speaker lineup.

The ZR650-CSi features 6.5-inch (165 mm) component woofers with Kurt Müller cones and suspensions, precision-machined field plates and die-cast alloy baskets. The woofer design benefits from JL Audio’s vast woofer design experience and advanced modeling systems.

The ZR component tweeters included in this system feature 1-inch aluminum domes with rubber-roll suspensions that damp unwanted ringing while delivering spectacular high-frequency extension. A flush-mounting fixture with a classy electro-formed ring provides a sophisticated touch in any installation.

ZR crossover networks are bi-amp capable and built with super-premium component parts, including U.S.-made Mills™ resistors mounted on an extruded aluminum heat sink, polypropylene capacitors, and segmented air-core inductors. Five levels of tweeter attenuation are provided, as well as four levels of mid-range presence adjustment, for twenty possible voicing combinations!

Woofer grilles are included, each consisting of a black grille tray and a black steel mesh grille with an electroformed “ZR” logo.

When nothing but the best will do, choose ZR.

Made in Germany, Sold as a pair.

Sonic character: Accurate and detailed

Check us out at:

Friend us on Facebook:http://facebook.com/tacotunes

Website: https://tacotunes.com

Add us a friend on Facebook:http://facebook.com/tacotunes

YouTube:http://youtube.com/tacotunes

Posted on 04/25/201310/19/2016 by admin — Leave a comment

JL Audio C5 650 Component Speakers – Toyota Tundra

JL Audio C5 650 Component Speakers

JL Audio C5 650 Component Speakers in Toyota Tundra

To install JL Audio C5 650 Component Speakers into your Toyota Tundra, you will want to use tacotunes.com speaker adapters designed to work in your Tundra. The JL Audio C5 650 Component Speakers require a 5.6” cutout diameter for the mid range speakers. The JL Audio C5 650 Component Speakers tweeters will require a 1.49″ cutout diameter.

Click HERE to check out our audio products for your Toyota Tundra

JL Audio C5 650 Component Speakers will fit you your Toyota Tundra without any cutting, drilling or modifying your Tundra.

Summary:

Mid range Driver: 5.6″ cutout diameter

Tweeter: 1.49″ cutout diameter

Top Mount Depth: 2 5/8″

JL Audio C5 650 Component Speakers Manual Toyota Tundra

C5-650

2-Way Component System: 6.5-inch (165 mm) Woofer, 0.75-inch (19 mm) Silk Dome Tweeter
The smoothness and transparency of a high-end silk dome tweeter combines with top-flight component woofer performance to create a loudspeaker system with exceptional refinement and dynamic capability.

The C5-650 component system features 6.5-inch (165 mm) component woofers with die-cast alloy baskets and Kurt Müller cones and suspensions. This woofer benefits from JL Audio’s vast woofer design experience and advanced modeling systems.

The C5 component tweeters are built with 0.75-inch silk dome diaphragms that deliver smooth, extended response, on and off axis. Flush-mounting and surface-mounting fixtures are included to fit a wide variety of installation needs. The flush-mount fixtures feature our RSR (Ratcheting Swivel Rotation) mechanism to allow precise tweeter aiming after installation.

C5 crossover networks are compact and built with premium component parts, including Mylar® capacitors and segmented air-core inductors. Four levels of tweeter attenuation are provided, as well as three levels of mid-range presence adjustment, for twelve possible voicing combinations!

Woofer grilles are included, each consisting of a black grille tray and a black steel mesh grille with an electroformed JL Audio logo.

Sonic character: Smooth and balanced

Made in Germany, Sold as a pair.

Check us out at:

Friend us on Facebook:http://facebook.com/tacotunes

Website: https://tacotunes.com

Add us a friend on Facebook:http://facebook.com/tacotunes

YouTube:http://youtube.com/tacotunes

Posted on 03/27/201310/18/2016 by admin — Leave a comment

Image Dynamics XS65 Component Speakers – Toyota Tundra

Image Dynamics XS65 Component Speakers Toyota Tundra

Toyota Tacoma Image Dynamics XS65 Component Speakers

Installation tips:

To install Image Dynamics XS65 Component Speakers into your Toyota Tundra you will want to use our custom size 5.6″ cutout diameter for the mid range speakers, the tweeter will require a custom sized hole. We are Image Dynamics authorized! You can purchase the speakers and accessories you will need to get these installed quickly and easily.

Click HERE to check out our audio products for your Toyota Tundra

You can purchase these from our shopping cart: XS65 Purchase www.tacotunes.com

Image Dynamics XS65 Component Speakers: The XS Series Components from Image Dynamics are the culmination of a engineering driven research and development project to produce sound performance that is without compromise.Powerfully detailed and dynamic in their musical output, they excel in the challenging automotive acoustic environment. XS Hybrid Components produce midrange with presence and detail without any coloration. The mid-bass carries weight and impact, and the highs are alive with detail and clarity without fatiguing harshness.Available in 6.5″ and 6×9″ models. An innovative speaker system, the XS Series allows multiple tweeter mounting options for the best in-car performance and ease of installation.

Speaker Size: 6.5″ Neo Component w/silk Tweeter

Resistance: 4 OHM Component

Rated Output: 25 -200w

Sensivity: 92db

Frequency Range: 55Hz – 25kHz

Top Mount Depth: 3.0″

Image Dynamics XS65 Component Speaker manual Toyota Tundra

Posted on 03/27/201310/11/2016 by admin — Leave a comment

Image Dynamics CTX65CS Component Speakers Tweeters – Toyota Tundra

Image Dynamics CTX65CS Component Speakers Tweeters

Image Dynamics CTX65CS Component Speakers Tweeters installing in your Toyota Tundra

Tacotunes.com is Image Dynamics Authorized. Please visit our shopping cart to purchase Image Dynamics CTX65CS Component Speakers Tweeters bundled with the parts you will need to get them installed quickly and easily.

Click HERE to check out our audio products for your Toyota Tundra

Image Dynamics CTX65CS Component Speakers Tweeters

Image Dynamics CTX65CS Component Speakers Tweeters: CTX Component Speakers are the affordable solution for the sound enthusiast seeking a high performance speaker system. Their high efficiency provides incredible detail and very high output levels while producing rich well-balanced sound with excellent tonal characteristics. More than the sum of the parts, the CTX components feature a long excursion mid-woofer design that handles high-power amplifiers effortlessly with low distortion allowing higher output levels. The Silk dome CTX tweeters deliver the dynamics and detail without listening fatigue or harshness.The CTX components performance is the product of proper materials and a well executed engineering design. This translates to neodymium magnet silk dome tweeters with swivel mount, mica-polymer composite cones that are stiff, yet light and well-damped butyl rubber surrounds. Crossover with 250 volt metalized polypropylene capacitors air core inductors and 3 position tweeter level control.

Speaker Size: 6.5″

Resistance: 4 OHM Component

Rated Output: 25 -200w

Sensitivity: 89db

Frequency Range: 55Hz – 25kHz

Top Mount Depth: 2.75″

Image Dynamics CTX65CS Component Speaker Manual Toyota Tundra
